Descripción
Specs:
| Platform | PC |
| Driving type | Direct Drive |
| Maximum Turning Angle | Limitless |
| Cover | Aluminum |
| Color | Black |
| Maximum Torque | 16 N·m |
| Size | 13 Inch |
| Maximum Power | 360W |
| Input voltage | 220V AC→36V DC |
| Encoder Resolution | 262144 ppr |
| USB Refresh Rate | 1000Hz |
| Indicator | YES |
| Quick Release | YES |
| Interface | Power Supply, Data, General Interface |
| Accessories | Instructions，Power Supply，USB Cable，Warranty Card，Screw |
| External Devices Adapter | Option |
| Mounting | 4-Hole Pattern on the Bottom, Side Mounting Support with Special BRKT |
| Mounting Bracket | Bottom Angle Adjustment Bracket/Side Fixing Bracket |
| Table Clamp | Optional |
| Side Mounting | YES |
| Emergency Stop | Option |
| L x W x H | 327mm x 170mm x 130mm |
| Mass(ALL) | 8.9kg |
| APP Function | YES |
| Shifting Indicator Light | YES |
GS (Formula) Wheel Specs:
| Grip Material | Alcantara® made in Italy |
| Frame and Front Plate Material | Forged carbon fibre |
| Shifter Paddle Material | 3 mm-thick forged carbon fibre |
| Size | 300mm GT standard wheel |
| Magnetic Shifter Paddles | 2 |
| Dual Clutch Paddles | 2 |
| Luminous Mechanical Keys | 10 |
| Thumb Knobs (pressable) | 2 |
| Band Knobs | 5 |
| LED Lamp Beads RGB | 10 |
| LED Colors | 7 for customization |
| Intelligent Telemetry | Yes |
| Light setting in MOZA Pit House | Yes |
| Knock-Down (K/D) Method | D1 spec quick release |
| Transmission Mode | Wireless |
| Paddle Sensor | Contactless photoelectric sensor |
| Dual Clutch Shifter Paddle Modes | Synthesis axis/Independent axis/button |
RS (Round or D Shape) Wheel Specs:
| Grip Material |
|
|
| Frame Material | Brushed Aluminum Alloy | |
| Panel Material | Forged carbon fibre | |
| Shifter Paddle Material | 3 mm-thick forged carbon fibre | |
| Size | 330mm GT Round or D Shape wheel | |
| Magnetic Shifter Paddles | 2 | |
| Dual Clutch Paddles | 2 | |
| Mechanical Keyboard Texture Buttons | 10 | |
| 20-segment Knob (Can Be Pressed) | 2 | |
| Universal Rocker (Can Be Pressed) | 5 | |
| Racing Horn | 1 | |
| LED Lamp Beads RGB | 10 | |
| LED Colors | Color customization | |
| Intelligent Telemetry | Yes | |
| Light setting in MOZA Pit House | Yes | |
| Quick release | D1 spec quick release | |
| Transmission Mode | Wireless | |
| Paddle Sensor | Contactless photoelectric sensor | |
| Dual Clutch Shifter Paddle Modes | Synthesis axis/Independent axis/button |
